Expandable Container House
Expandable container houses, also known as biplane expandable containers or folding containers, are an innovative type of modular architecture. Their core feature lies in their folding or sliding structure, which allows them to remain compact during transport and quickly unfold for use, thus maximizing space utilization.

Contcat: Michelle

Phone: +8618364117631

Whatsapp: +8618364117631

Address: Hanyu Jingu, Licheng District, Jinan City,

Shandong Province, China

Product Introduction

Size specifications (before/after expansion)length6m/9m; 8m/12m (Standard size, customizable)
width2.4m/4.8m; 3m/6m (single-sided/double-sided expansion optional)
high2.8m/2.8m (Indoor clear height is above 2.5m, height remains unchanged after expansion)
Expanding areaExpanding to one side increases the area by 6-8 square meters, while expanding to both sides increases it by 12-16 square meters.
Main structureFrame materialQ235B steel frame, 3.5mm wall thickness, hot-dip galvanized for corrosion protection, wind resistance level 12, seismic intensity level 7.
Wall materialOuter layer of color steel plate (0.8mm) + polyurethane insulation cotton (75mm) + inner layer of fireproof gypsum board, providing sound and heat insulation, fire rating B1.
Expansion AgencyThe hydraulic/manual expansion mechanism is easy to operate, ensures no shaking after expansion, and has excellent sealing performance.
Roof and groundRoofing materialColor steel sandwich insulation panels, waterproof membrane installation, 20° slope, leak-proof and snow-resistant.
floor materialAnti-slip and wear-resistant reinforced flooring, with a base layer of patterned steel plate + cement leveling, load-bearing capacity ≥300kg/㎡, seamless connection to extended areas.
Door and window configurationwindowThermally broken aluminum casement/sliding windows, double-glazed tempered glass, sound and heat insulation, with mosquito screens, and floor-to-ceiling windows can be added on the extended side.
DoorClass A security entrance door, aluminum alloy door frame, equipped with fingerprint lock, airtight and soundproof, double door can be customized.
Additional doors and windowsCustomizable sliding doors and viewing windows to suit the lighting needs of expanded spaces.
Interior configurationWall treatmentEco-friendly integrated wall panels/bamboo fiber panels, available in multiple colors, easy to clean, odorless, and allow for seamless splicing of expanded wall areas.
suspended ceilingAluminum ceiling panels offer a smooth and aesthetically pleasing finish, with pre-installed mounting spaces for lighting fixtures, air conditioning, and fresh air systems.
Circuit configurationStandard copper core wire, equipped with distribution box, residual current device, multiple sockets and switches, and reserved interfaces for air conditioner, water heater and fresh air system.
