Mobile Container Shop

Mobile Container Shop
The Mobile Container Shop integrates ultimate flexibility, high-value personalized design, and efficient business value, becoming a new species of business that disrupts the traditional store model.

Contcat: Michelle

Phone: +8618364117631

Whatsapp: +8618364117631

Address: Hanyu Jingu, Licheng District, Jinan City,

Shandong Province, China

Product Introduction

SpecificationStandard 20 feet (single bed)Customized 3×6m (mainstream trend among online influencers)40 ft (double berth/combination)Mini pop-up edition
External dimensions6058×2438×25916000×3000×2800~300012192×2438×28003000×2400×2600
Indoor clear height2.4m2.6~2.8m2.6m2.4m
usable area14.8㎡18㎡29.6㎡7.2㎡
Self-respect2.8~3.2 tons3.0~3.5 tons5.5~6.0 tons1.8~2.2 tons
Adapted scenariosMilk tea / Coffee / RetailFood & Beverage / Cultural & Creative Products / Pop-up StoresMulti-brand store / supermarketMarket / Temporary Location
frameQ235B galvanized square/channel steel (80×80, 100×100mm), wall thickness 3~5mm, welded + bolted connection, hot-dip galvanized + fluorocarbon paint, rust prevention grade C4, service life 15~25 years.
Walls / Ceiling50~100mm thick composite sandwich panel (outer layer 0.5~0.8mm color steel/galvanized sheet, inner layer rock wool/polyurethane), Class A/B1 fireproof, thermal conductivity ≤0.04W/(m・K)
floor18mm thick non-slip cement fiberboard + PVC/wood grain flooring, load-bearing capacity **≥500kg/㎡**, waterproof and non-slip.
Doors and windowsThermally broken aluminum tempered glass door (800×2000mm) + lift-up sales window / floor-to-ceiling glass curtain wall (5+12A+5 double-glazed tempered glass), with screen and sealing strip, IP65 waterproof.
Wind resistance levelLevel 8-10 (wind pressure 0.6-1.0 kN/m²)
Temperature resistance-40℃~+80℃
